Details:
Outer diameter: 160mm
Bore size: 20mm
Width of cut (b1) / Base bl. thickness (b2): 2.0/1.4 mm
Number of teeth: 42
Bore with reduction ring: 16 mm
Tooth shape: TCG
Max. rotation speed (RPM): 9500
Cutting result: Fine cut
Hook angle ° α: 5
Relief angle ° β: 13

IMAGE IS JUST FOR SAMPLING SIZE AND DETAILS ARE AS PER PRODUCT HEADING
_______________________________________________________________________________

Details:
Outer diameter: 190mm
Bore size: 30mm
Width of cut (b1) / Base bl. thickness (b2): 2.2/1.6 mm
Number of teeth: 54
Bore with reduction ring: –
Tooth shape: TCG
Max. rotation speed (RPM): 8000
Cutting result: Fine cut
Hook angle ° α: 5
Relief angle ° β: 13

IMAGE IS JUST FOR SAMPLING SIZE AND DETAILS ARE AS PER PRODUCT HEADING
_______________________________________________________________________________

Details:
Outer diameter: 254mm
Bore size: 30mm
Width of cut (b1) / Base bl. thickness (b2): 3.0/2.2 mm
Number of teeth: 80
Bore with reduction ring: 25.4
Tooth shape: TCG
Max. rotation speed (RPM): 6000
Cutting result: Fine cut
Hook angle ° α: 7
Relief angle ° β: 13

IMAGE IS JUST FOR SAMPLING SIZE AND DETAILS ARE AS PER PRODUCT HEADING
_______________________________________________________________________________

Details:
Outer diameter: 305mm
Bore size: 30mm
Width of cut (b1) / Base bl. thickness (b2): 3.0/2.2 mm
Number of teeth: 80
Bore with reduction ring: 25.4
Tooth shape: TCG
Max. rotation speed (RPM): 5000
Cutting result: Fine cut
Hook angle ° α: 7
Relief angle ° β: 13

IMAGE IS JUST FOR SAMPLING SIZE AND DETAILS ARE AS PER PRODUCT HEADING
_______________________________________________________________________________

Details:
Outer diameter: 184mm
Bore size: 20mm
Width of cut (b1) / Base bl. thickness (b2): 2.2/1.4 mm
Number of teeth: 24
Bore with reduction ring: 16mm
Tooth shape: ATB
Max. rotation speed (RPM): 8000
Cutting result: Coarse cut
Hook angle ° α: 18
Relief angle ° β: 13

IMAGE IS JUST FOR SAMPLING SIZE AND DETAILS ARE AS PER PRODUCT HEADING
_______________________________________________________________________________

Details:
Outer diameter: 184mm
Bore size: 20mm
Width of cut (b1) / Base bl. thickness (b2): 2.2/1.4 mm
Number of teeth: 60
Bore with reduction ring: 16mm
Tooth shape: ATB
Max. rotation speed (RPM): 8000
Cutting result: Fine cut
Hook angle ° α: 16
Relief angle ° β: 15
